  • Safe working load of 135 kg patient weight
  • Ergonomics smooth movement to raise the back section up to 70 degree with help of lockable hydra-pneumatic system.
  • Provided with three nos. drawer.
  • Suitable height to examine the patient.
  • Rexine cushioned mattress fitted with 12mm ply wood and 50mm PU foam consisting of two sections a total of 62mm height.

Safe working load of 135 kg patient weight All the mild steel components are chemically pre-treated by individual dip tank process including hot decreasing, hot pickling, hot zinc phosphate in nine well-maintained treatment plants to have good adhesive property to the painted surface. Zinc phosphate treatment avoids rust penetration in case the painted surface is damaged. Oven baked powder coating epoxy polyester antibacterial with dry film thickness of not less than 50 microns. The painted surface is easy to clean Technical Specification Overall size 2000mm L X 610mm W X 890mm H. The back section of size 610mm W X 460mm L Construction: Front framework made from strong 40mm X 20 X 1.6mm CR ERW mild steel rectangular tube of a single length. The back made from CR ERW round 25mm diameter X 1.2mm wall thickness tube with the support of 50mm X 20 X 2mm CR ERW mild steel rectangular tube. The legs are made from CR ERW round 32mm diameter X 1.2mm wall thickness. The drawers are made from 1mm CRCA mild steel sheet. Longitudinal support provided consisting of 2nos. CR ERW round 25mm diameter X 1.2mm wall thickness. Two sections top are made from 12mm plywood and 50mm PU foam, total height 62mm with rexine cover. All the components are manufactured in jigs & fixtures to have uniform shape and size. This assures proper after sales service of the components. Total net weight 53.000Kg.
